6m 4 Sections Aluminium Telescopic Mast

1) 3.5 meter telescopic mast

2) 6.5 meter telescopic mast, around 7 meters from ground to top if you installed on the trailer

3) 8.5 meter telescopic mast, around 9 meters from ground to top if you installed on the trailer

Manual and electric for some items.

Above drawing is an example

Core Technical Advantages

1. High-Strength Aluminium Alloy Material
•Lightweight & Durable: High-strength aluminium alloy material is 30% lighter than steel masts, reducing the overall weight of mobile solar equipment and facilitating on-site deployment.
•Corrosion & Rust-Proof: Seamless extrusion forming and surface oxidation treatment, no rust even in humid, coastal or industrial environments-realizing years of maintenance-free use.
•Anti-Cut & Anti-Vandal: Integrated aluminium structure with no welding seams, resistant to cutting and physical damage, suitable for outdoor harsh environments.

2. Excellent Windproof & Load-Bearing Performance
•117kph Windproof Rating: Aerodynamic round design reduces wind pressure by 25% compared to square masts, can withstand wind speed up to 117kph (32.5m/s), stable operation in strong wind.
•40kg Load Capacity: Precision structural design ensures stable load-bearing for surveillance cameras, small LED lights and communication antennas (≤50kg), no deformation at full extension.
•Reinforced Section Connection: Each telescopic section is equipped with anti-slip locking devices and reinforced joints, ensuring firm connection and uniform load distribution.

3. Dual Lifting Modes & Easy Operation
•Manual Winch Lifting: Cost-effective manual winch with labor-saving gear design, 1 person can complete lifting/retracting operation, no power supply required-ideal for remote off-grid scenarios.
•Electric Lifting: Motor-driven electric lifting with precise height adjustment, fast lifting speed (6m extension in 1-2 minutes), suitable for frequent height adjustment needs.
•One-Click Locking: Each section is equipped with a quick-lock mechanism, which can fix the height instantly after extending to the required position, safe and reliable.

4. Universal Compatibility & Installation
•Universal Mounting Base: Standard flange base design, compatible with solar surveillance towers, light towers, mobile trailers and fixed brackets-easy to install with bolts.
•Compact Retracted Size: Retracted length is only 1.8-2.2m (varies by model), saving storage and transportation space, convenient for container loading and long-distance shipping.
•Wide Application Matching: Perfectly matches BIGLUX solar surveillance towers, light towers and other mobile solar equipment, also compatible with third-party outdoor devices.

5. Industrial-Grade Production Process
•Precision Laser Cutting: Adopts AMADA laser cutting equipment for high-precision section cutting, ensuring seamless fit between telescopic sections.
•Robot Welding: Automatic robot welding process for joints, stable welding quality, high structural strength and no welding defects.
•Environment-Friendly Powder Coating: Phosphating pretreatment + electrostatic powder coating, enhanced corrosion resistance and surface wear resistance, beautiful and durable.
