Products Description
| Solar Panel | 3 × 435W,Mono-Crystalline |
| GEL Battery | 6 × 150Ah,DC12V,10800W·h |
| Spring Cable | 2*CAT6 + 1*awg13+1*awg16 cable |
| Controller | 60A MPPT,95% Efficiency |
| Mast | Steel Q235,Square Telescopic type,6.5 m,5 Sections |
| Trailer | US/EU/AU Standard,Ball Hitch |
| Charging Time | 6.9 hours |
| Running Time | 3 Days for 120W |
| System Voltage | DC24V |
Advantages with Pull-Out Solar panel Design:
-
Better protect solar panel, extend using life.
-
Smaller size make transportation easier.
-
Smaller size saving shipping cost.
Applications: A portable solar surveillance trailer with a thermal imaging camera can be used in various scenarios, including:
a. Security: It can be deployed in areas requiring enhanced security, such as construction sites, remote facilities, or temporary events, to detect intrusions or suspicious activities.
b. Wildlife Monitoring: The system can be used for wildlife research, conservation, or management. The thermal imaging camera can help monitor animal behavior, track migration patterns, or detect poaching activities.
c. Perimeter Surveillance: It can be utilized to monitor large perimeters, such as borders, industrial sites, or critical infrastructure, to detect breaches or unauthorized access.
d. Emergency Response: During natural disasters or emergency situations, the system can provide surveillance capabilities in areas where infrastructure is damaged or absent, assisting in search and rescue operations or assessing the extent of the damage.
Portable solar surveillance trailers with thermal imaging cameras offer a flexible and self-sustaining solution for monitoring and surveillance needs in remote or temporary locations.
A-Frame Drawbar Design
To achieve a gravity balance and safer, energy-saving transportation, the telescopic mast and drawbar are aligned in the same direction.
Two Doors Design, Easier Maintenance
To facilitate customer maintenance of the battery and other parts, we have designed two separate doors, allowing them to access these components without opening the control system door while the system is operational.
Forklift Hole, Easier Transportation
The forklift hole makes transportation easier by allowing the object to be lifted and moved with a forklift.
Ring For HIAB Hook,Helicopter or Lorry Transportation
A ring on each side provides a secure attachment point
Why Choose Us
1 . Strong expertise in trailer and solar latest technologies.
2 . Broad experience in trailer and solar applications.
3 . insatiable thirst for smart and intelligent mobile cCTV tower system.
4 . great heart of contribution to the most energy saving and environment friendly world.
