Solar-Powered Mobile Surveillance Trailer With High Definition Hikvision Dome Cameras For Security Working Site
Mobile Portable Solar Surveillance Trailer Specification:
| Model | BL2P-G7MHSSOB |
| Name | Mobile Solar CCTV Tower |
| Solar Panel | 2 × 450W,Mono-Crystalline |
| GEL Battery | DC24V,9600W·h |
| Mounting Box | 2*CAT6+2*2.5mm²+6*1.5mm² power cable |
| Controller | 50A MPPT,95% Efficiency, With Remote Battery Monitoring |
| Mast | Steel Q235, Square Telescopic type, 7 m, Manual Winch Lifting, 70kg Load, Windproof |
| Trailer | US/EU/AU Standard, Ball Hitch, Single Axle, Manual Outrigger |
| Charging Time | 9 hours |
| Running Time | 3 Days for 90W |
| System Voltage | DC24V |
| Weight | 1100KG |
| Container Loading Plan |
6units for 20GP 14units for 40HQ |
CAMERA RECOMMENDATION
2pcs HIKVISION 4MP Dome cameras
Hikvision DS-2DF8C425MHS-DELW(T5) 4MP 25× Network Speed Dome adopts 1/1.8" progressive scan CMOS chip. With the 25 × optical zoom lens, the camera offers more details over expansive areas. This series of cameras can be widely used for wide ranges of high-definition, such as the rivers, forests, roads, railways, airports, ports, squares, parks, scenic spots, stations and large venues, etc. Dual sensor 1/1.8" progressive scan CMOS
High quality imaging with 4 MP resolution
Excellent low-light performance with DarkFighterX technology
25 × optical zoom and 16 × digital zoom provide close up views over expansive areas 300 m IR distance
Water and dust resistant (IP67)
Supports face capture to detect, capture, grade, and select faces in motion Supports road traffic to detect vehicles
Efficient H.265+/H.265 compression technology
140 dB WDR, 3D DNR, HLC, BLC, EIS, defog
The trailer body is divided into 3 parts, one is for batteries, one for backup generator, and one for the controling panel and MPPT controller.
The Solar-Powered Mobile CCTV Trailer with Hybrid System can be self work 24/7/365. Just need to add some fuels each 1-2 months. The gasoline 3KW generator is the back up in case of some cloudy or rainy days. And if there is no electricty, the generator will work automatically.
If more details, please contact us. Biglux cooperates with reliable suppliers, choose high quality materials and pays attention to details. Hope we can be your partner here.
