Product Description
Moduel | BLSP-300 | BLSP-320 | BLSP-330 | BLSP-340 | BLSP-345 |
Rated Maximum Power at STC | 300 | 320 | 330 | 340 | 345 |
Open Circuit Voltage(Voc/V) | 45.28 | 45.86 | 46.34 | 46.91 | 47.13 |
Maximum Power Voltage(Vmp/V) | 36.77 | 37.35 | 37.57 | 38.17 | 38.39 |
Short Circuit Current(Isc/A) | 8.71 | 8.99 | 9.29 | 9.41 | 9.48 |
Maximum Power Current(Imp/A) | 8.16 | 8.57 | 8.78 | 8.91 | 8.99 |
Module Efficiency(%) | 15.48 | 16.51 | 17.02 | 17.54 | 17.80 |
Power Tolerance | -0~+3% | ||||
Standard Test Condition(STC) | Irradiance 1000W/m2, Cell Temperature 25℃, Air Mass1.5 | ||||
Detailed & Production
Glass
Antireflective glass
Translucency of normal luminance is increased by 2%
Module efficiency is increased by 2%
Self-cleaning function
Service life is as long as 25 years (30 years optional)
Solar Cell
High Efficiency PV Cells
Appearance Consistency
Color sorting ensure consistent appearance on each module
Anti-PID
Frame
Conventional frame
Silver or black frames are optional
Boost bearing capability and prolong service life
Serrated-clip design tensile strength
Seal-lip designglue injection
Junction box
> Conventional standalone edition and engineering custom edition
> Quality diode ensures module running safety
> IP67 protection level
> Heat dissipation
> Long service life
By sea | Delivery from Shenzhen seaport |
By air | Departure from Shenzhen Bao'an Airport or HK International Airport |
By express | By TNT/DHL |
Why chose us ?
1, The solar modules in Shine Solar are with rigorous test, passed the TUV, ISO, CE, ROHS certification.
2, working with customers is not just a single sales man, is our sales department + engineering + production department in a entire team.
3, Alibaba provide a high secured credit to us, six months accumulated more than one and forty points million US. dollars, and 2018 year it will expected 5 million US. dollars.
4, customers are highly satisfied with us, we have been rated as the most popular supplier in Alibaba by customers for three consecutive years.
5, We provide 25 years warranty for glass PV solar panels, if any damage, we will compensate to you in free.
